Aluminum Round Pipe

Product Description

Aluminum tubing benefits a wide variety of industries. Outdoor recreation manufacturers use tubing to construct materials like tent poles, camp chair frames, and outdoor tables. In the medical industry, aluminum tubing appears in wheelchair frames, collapsible stretchers, bed frames, and crutches.

Product Name	Aluminium steel tube/Aluminium pipe /Aluminum tube /Aluminum pipe
Standard	JIS, AiSi, ASTM, GB, DIN, EN, GB/GB/T6893-2000,GB/T4437-2000,ASTM B210,ASTM B241,ASTM B234,JIS H4080-2006,etc
Grade	1000 Series,3000 Series,5000 Series,6000 Series,7000 Series, etc.
Material	1060,1200,1100,2024,2124,3003,3004,5050,5083,5154,5454,5652,5086,5056,5456,5754,6061,6062,6063,7075,etc
Surface Treatment	Oxidation, electrophoresis coating, fluorine carbon spraying, powder coating, wood grain transfer printing, mechanical drawing, mechanical polishing, sand blasting
Temper	T3 - T8
Shape	Round/Square/Oval
Application	Aluminum tube is widely used in all walks of life, such as: automobile, ship, aerospace, aviation,electronics, agricultural and mechanical and electrical, home, etc
Outer Diameter	4-630mm or as required
Wall Thickness	0.15-40mm or as required
Length	1000mm-12000mm or as required
Inspection	Fully accept all the third party to test before shipment.
Packing	Standard Export Seaworthy Package.Wooden Package.Suit for all kinds of transport,or as required.
Delivery Time	7-10 working days after receiving the deposit or both parties negotiate according to the order quantity
Payment Terms	30%T/T Advance + 70% Balance
MOQ	2 Tons

6061 6063 5083 5086 6060 Anodised Aluminium Rectangular alloys round Pipe

The advantages of aluminum alloy are lightweight, excellent electrical and thermal conductivity, high corrosion resistance and ductility.

Aluminum alloy is soft and usually alloyed with copper, zinc, magnesium, silicon, manganese and lithium to increase strength. When aluminum alloy is exposed to air, an anti-oxidant coating will be formed instantly to protect products. Aluminum alloy is one of the lightest metals. The application of products ranges from precision technology to daily commodities.

Standard Specification: GB/T 6892, GB/T 6893, ASTM B221, EN754, EN 755

Available Size Range

Dimension	Range
Outside	8.0~350mm for Round
Diameter	15x15mm~250x250mm for Square 10x20mm~200x250mm for Rectangle
Wall Thickness	1.0~40mm
Length	1,000~6,000mm

- Production Process: Extruded, Cold Drawn
- Form & Image: Round, Square, Rectangle
- Surface Finish: Mill Finish, unless otherwise specified
- Surface Protection: Paper interleaved

Application

Aluminum alloy tube and pipe can be widely used in construction, machinery, electronics, sports equipment, advertising, transportation, consumer goods, furniture, aviation, military and other applications. We also provide anodizing, bending, welding, polishing and punching service.

Temper	Definition
O	Annealed
H14	Strain Hardened, 1/2 Hard
H112	Slightly strain harden from working at an elevated temperature or from limited amount of cold work
T4	Solution heat-treated and naturally aged
T5	Cooled from an elevated temperature shaping process and then artificially aged
T6	Solution heat-treated and then artificially aged
T651	Solution heat-treated, stress-relieved by stretching a controlled amount and then artificially aged
T66	Solution heat-treated and then artificially aged - mechanical property level higher than T6 achieved through special control of the process (6000 series alloys)
T6511	Solution heated-treaded, stress-relieved by stretching a controlled amount and then artificially aged. Minor straightening is allowed after stretching to comply with standard tolerances

Comparison of Alloy Designations for Aluminum Products

Alloy Series	Chinese Standard	American Standard	European Standard
5xxx Series	5052	5052	EN AW-5052
	5083	5083	EN AW-5083
	5754	-	EN AW 5754
6xxx Series	6005	6005	-
	6060	6060	EN AW-6060
	6061	6061	EN AW-6061
	6063	6063	EN AW-6063
	6082	6082	EN AW-6082
	6463	6463	-

5086 Aluminum Pipe

5086 aluminum pipe is a high strength magnesium alloyed aluminum product primarily used in the marine industry due to its excellent corrosion resistance, especially to seawater. In addition to good corrosion resistance, this alloy also has good weldability characteristics.

6061 Aluminum Pipe

6061 aluminum pipe is a magnesium and silicon alloyed aluminum material. This good all-purpose alloy has good corrosion resistance and formability and has medium strength. It has good machining characteristics and has excellent appearance after anodizing.

6063 Aluminum Pipe

6063 aluminum pipe is made from a popular heat treatable magnesium/silicon alloy. This alloy has excellent corrosion resistance and weldability. Due to its finer grain structure, this is an excellent alloy choice for anodizing. Applications include air cylinder, electrical bus conductor and architectural.

5083 Aluminum Pipe

This magnesium alloyed aluminum product is primarily used in the marine industry due to its excellent corrosion resistance, especially to seawater. In addition to good corrosion resistance, 5083 aluminum pipe also has good weldability characteristics for fabricating vessels.
